OS
|
Android 4.4.2
|
|
Language
|
chinese
and english, and so on, multi language
|
|
CPU
|
Cortex
A7 1.3 GHz
|
|
Memory
|
LPDDR3:
1GB/2GB , eMMC:8GB/16GB
|
|
TF/SD
|
32
GB microSD , SDHC，single SIM
|
|
Interface/IO
|
Bottom
IO connector(USB, charger,Detect,GND)
back IO connector(UART, RFID, Power, GND)
|
|
Sensor
|
light，distance，acceleration，compass，hall
magnetic
|
|
LED
|
red/blue/green
LED
|
|
Charging term
|
<5 Hours, with adapter
<3 with docking station
|
|
working time
|
16.5
hours
|
|
standby
|
50days
|
|
Reading function
|
|
Light source
|
617
nm red light; 625 nm LED
|
|
angel
|
39°
(H) x 25° (V);
|
|
Moving capactiy
|
Up
to 4 in. (10 cm) per second;
|
|
angel
|
±
60°
|
|
Code standard
|
1D
barcode; UPC/EAN/JAN, Code 39, Code 128, Code 32, Code 93,Codabar/NW7,
Interleaved2 of 5, Matrix 2 of 5, MSI, Telepen, Trioptic, China Post; Postal: Australian Post, British Post,
Canadian Post, China Post, ID tag, Japanese Post, Netherlands (KIX) Post,
Korea Post, Postnet, Planet Code;
|
|
2D barcode; Aztec Code, Data Matrix, QR Code,
Micro QR Code, MaxiCode, Han Xin Code; 2D Stacked:PDF417, MicroPDF417,
GS1-128;
|
|
OCR option:OCR-A, OCR-B, E13B(MICR)
|
|
RFID
|
UHF
RFID
support EPC Class 1 Gen 2（ISO
18000-6C）label
working frequency: US 902-928MHz；ETSI（欧洲）865-867MHz
SRRC-MII（中国）840-845MHz、920- 925MHz
|
|
Communication
|
|
WLAN
|
IEEE
802.11 b/g/n(fast roaming)
|
|
WLAN security
|
WEP,
802.1x, TKIP, AES, LEAP, PEAPv0,
PEAPv1, EAP-M, SCHAPv2
EAP-GTC, EAP-TLS, EAP-TTLS, WPA-PSK, WPA2,WAPI
|
|
WWAN
|
GSM850/900/1800/1900Mhz
WCDMA850/900/1900/2100Mhz
|
|
WPAN
|
Bluetooth 4.0
|
|
BT
|
GAP,GEOP,SPP,DUN,
HFP,HSP,HID,OPP,PAN, ActiveSync-Over-Bluetooth,A2DP,AVRCP,PBAP
|
|
GPS
|
GPS/A-GPS
|
|
intercom
|
Freq
400-470MHz, suport talk back with Moto, distance is 3-5 kilometer
|
|
Physic Spec
|
|
Screen
|
4.'
WVGA(480*800); sunshine readable
|
|
Touch Panel
|
GFF
capacity touch, gorrila glass，hardness>7H
|
|
Camera
|
back
8M
|
|
Audio
|
Speaker,
double Mico
|
|
charger port
|
charger
adapter, charger station
|
|
battery
|
5000mAh
|
|
size
|
201*62*26
mm
|
|
weight
|
330g
|
|
Enviroment
|
|
temperature
|
-20°C
~ +50°C
|
|
Storeage temperature
|
-30°C
~ +70°C
|
|
Humility
|
10%
~ 90%
|
|
};
|
