Type
|
Details
|
Descriptions
|
|
Product
Form
|
Type
|
Access control device
|
|
Dimensions
|
TBD
|
|
Wight
|
TBD
|
|
Touch Panel
|
process
|
5points Capacitive，G+FF，Corning Gorilla Glass, COF，I2C
|
|
Rigidity
|
above 7H-Anti-scratch，support
glove/wet hand touch
|
|
LCD Panel
|
Screen Size
|
5.5" TP and screen adopts full joint technology
|
|
Screen
Resolution
|
1080X1920 IPS Screen MIPI 30Pin
|
|
Brightness
|
Min 350 cd/m2
|
|
Battery
|
Type
|
Lithium-ion polymer battery
|
|
Capacity
|
3.7V/3000MAH
|
|
System hardware configuration:
|
|
Type
|
Details
|
Descriptions
|
|
CPU
|
Type
|
Intel® Atom™ x5 Z8350 Processor
|
|
Speed
|
2M Cache, up to 1.92 GHz
|
|
GPU
|
Type
|
Gen8-LP 10/12EU up to 600MHz
|
|
RAM Memory
|
LPDDR3
|
4GB LPDDR3 253Ball
|
|
ROM Flash
|
EMMC5.0
|
32GB
|
|
Camera
|
Front
|
MIPI/5MP（OV5648）
|
|
Speaker
|
waterproof speake
|
Built-in 8Ω/0.8W waterproof speaker x 2
|
|
Microphone
|
waterproof Microphone
|
Sensitivity::-42db, output resistance2.2kΩ
|
|
infrared transducer
|
Built-in
|
support (for use at front of device to get
notification when something is)
|
|
Light sensor
|
Built-in
|
support((for use at front of device to adjust
the screens brightness)
|
|
|
